Let \(q(x)=2^x\) and \(h(x)=-0.5\cdot 2^{x+2}-3\). Describe, in order, the transformations that produce the graph of \(h\) from the graph of \(q\).
Hints
- A negative coefficient outside the function creates a reflection across the x-axis.
- Compare the rule with the form \(a q(x-c)+d\).
- A coefficient with absolute value between \(0\) and \(1\) creates a vertical compression.
- Determine the direction of the shift from the expression \(x+2\).
Solution
1. Replacing \(x\) with \(x+2\) shifts the graph left \(2\) units.
2. Multiplying the output by \(0.5\) vertically compresses the graph by a factor of \(0.5\).
3. The negative sign reflects the graph across the x-axis.
4. Subtracting \(3\) shifts the graph down \(3\) units.
Answer
Shift left \(2\) units, vertically compress by a factor of \(0.5\), reflect across the x-axis, and shift down \(3\) units.
