A cable pulls a boat with a force of \(65\,\text{N}\), directed north of west. The westward component is \(25\,\text{N}\). Let \(\theta\) be the angle measured counterclockwise from east.
a) Find \(\cos(\theta)\). Then use \(\sin^2(\theta)+\cos^2(\theta)=1\) to find \(\sin(\theta)\).
b) Find the northward component of the force.
Hints
- Which trigonometric ratio relates the horizontal component to the total force?
- How can the Pythagorean identity give sine from a known cosine value?
- Use the direction of the force to choose the sine sign.
- How do you turn the sine ratio into a force in newtons?
Solution
1. The westward component is negative, so \(\cos(\theta)=\frac{-25}{65}=-\frac{5}{13}\).
2. Use the Pythagorean identity: \(\sin^2(\theta)=1-\cos^2(\theta)=1-\frac{25}{169}=\frac{144}{169}\).
3. The force points north, so sine is positive: \(\sin(\theta)=\frac{12}{13}\).
4. The northward component is \(65\cdot\frac{12}{13}=60\,\text{N}\).
Answer
a) \(\cos(\theta)=-\frac{5}{13}\) and \(\sin(\theta)=\frac{12}{13}\), using \(\sin^2(\theta)=1-\cos^2(\theta)\)
b) \(60\,\text{N}\) north
