Maia launches a ball from ground level at an angle \(\alpha\) with initial speed \(v_0\). Ignore air resistance. Let \(x\) and \(f(x)\) be measured in meters, let \(v_0\) be measured in \(\text{m/s}\), and let \(g>0\) be measured in \(\text{m/s}^2\). Assume \(0^\circ<\alpha<90^\circ\). The trajectory is
\(f(x)=-\frac{g}{2v_0^2\cos^2\alpha}x^2+x\tan\alpha\).
a) Show that the horizontal range is \(R=\frac{2v_0^2}{g}\sin\alpha\cos\alpha\), and determine the maximum height of the ball.
b) Use \(\sin(2\alpha)=2\sin\alpha\cos\alpha\) to rewrite the range and explain why the range is greatest when \(\alpha=45^\circ\).
c) For a fixed launch angle \(\alpha\), explain how the maximum height depends on \(v_0\). What happens to the maximum height if \(v_0\) is doubled?
Hints
- For the range, look for the nonzero x-intercept of the trajectory.
- Use the symmetry of a parabola to locate the vertex from its two x-intercepts.
- Rewrite the angle-dependent part of the range using the supplied double-angle identity.
- For the speed comparison, focus on how \(v_0\) appears in the maximum-height expression.
Solution
1. Set \(f(x)=0\) and factor out \(x\). Besides \(x=0\), the nonzero root is \(R=\frac{2v_0^2}{g}\sin\alpha\cos\alpha\).
2. The roots are \(0\) and \(R\), so the vertex occurs at \(x=R/2=\frac{v_0^2\sin\alpha\cos\alpha}{g}\). Substituting this x-value into \(f\) gives \(h_{\max}=\frac{v_0^2\sin^2\alpha}{2g}\).
3. Using the double-angle identity, \(R=\frac{v_0^2}{g}\sin(2\alpha)\).
4. Since \(0^\circ<2\alpha<180^\circ\), \(\sin(2\alpha)\) is largest when \(2\alpha=90^\circ\). Therefore, the horizontal range is greatest at \(\alpha=45^\circ\).
5. For fixed \(\alpha\), \(h_{\max}\) is proportional to \(v_0^2\). Replacing \(v_0\) by \(2v_0\) multiplies the maximum height by \(4\).
Answer
a) \(R=\frac{2v_0^2}{g}\sin\alpha\cos\alpha\), and \(h_{\max}=\frac{v_0^2\sin^2\alpha}{2g}\).
b) \(R=\frac{v_0^2}{g}\sin(2\alpha)\), which is greatest at \(\alpha=45^\circ\).
c) For fixed \(\alpha\), the maximum height is proportional to \(v_0^2\). Doubling \(v_0\) quadruples the maximum height.
