A fair coin is tossed independently three times. Let \(X\) be the number of tails.
Give a written plan for a probability bar chart of \(X\) that someone else could draw accurately. State the horizontal-axis labels, a vertical-axis range and tick spacing, and each bar's position and height. Explain whether the bars should touch.
Hints
- Count how many ordered toss results have each possible number of tails.
- What should each axis show, and which axis needs a numerical probability scale?
- Could every bar height be shown exactly on one simple scale?
- Are the outcomes separate values or intervals?
Solution
1. There are \(2^3=8\) equally likely ordered toss results.
2. The numbers of results with \(0\), \(1\), \(2\), and \(3\) tails are \(1\), \(3\), \(3\), and \(1\).
3. Put the number of tails on the horizontal axis, labeled \(0,1,2,3\), and probability on the vertical axis. One suitable vertical scale runs from \(0\) to \(\frac{1}{2}\) in steps of \(\frac{1}{8}\).
4. Draw separate bars with positions and heights \((0,\frac{1}{8})\), \((1,\frac{3}{8})\), \((2,\frac{3}{8})\), and \((3,\frac{1}{8})\). The bars do not touch because the count is discrete.
Answer
Horizontal axis: number of tails \(0,1,2,3\). Vertical axis: probability from \(0\) to \(\frac{1}{2}\), ticks every \(\frac{1}{8}\). Separate bars: \((0,\frac{1}{8})\), \((1,\frac{3}{8})\), \((2,\frac{3}{8})\), \((3,\frac{1}{8})\).
