A suspension bridge spans between vertical towers at \(x=0\,\text{m}\) and \(x=100\,\text{m}\). Each tower is \(30\,\text{m}\) high, and the roadway lies along the x-axis. For \(0\le x\le100\), the main cable is modeled by \(f_a(x)=ax(x-100)+30\), where \(a>0\).
a) Show that \(0<a\le0.012\) is required for the cable to stay at or above the roadway.
b) Find \(a\) if the cable's lowest point is exactly \(5\,\text{m}\) above the roadway.
c) For this value of \(a\), find the acute angle the cable makes with the horizontal at the left tower.
Hints
- Find the vertex of the parabola.
- Translate “stay at or above the roadway” into an inequality for the minimum value.
- Differentiate to find the slope at the tower.
- Use the tangent relationship between slope and angle.
Solution
1. The parabola's lowest point occurs halfway between the towers, at \(x=50\). Its height is \(f_a(50)=30-2500a\).
2. To stay at or above the roadway, the minimum height must satisfy \(30-2500a\ge0\). Therefore, \(a\le0.012\). Together with \(a>0\), this gives \(0<a\le0.012\).
3. If the minimum height is \(5\,\text{m}\), then \(30-2500a=5\), so \(a=0.01\).
4. For \(a=0.01\), \(f_a'(x)=0.02x-1\). At \(x=0\), the slope is \(-1\). The acute angle relative to the horizontal is \(\arctan(1)=45^\circ\).
Answer
a) \(0<a\le0.012\)
b) \(a=0.01\)
c) \(45^\circ\)
