One model for the cross section of a storage building uses the parabola \(f(x)=8-0.125x^2\) on \([-8, 8]\). The midpoint of the floor is \(M(0, 0)\), and each coordinate unit represents one meter.
a) Show that the floor is \(16\,\text{m}\) wide and the maximum height is \(8\,\text{m}\).
b) Let \(P(x, f(x))\) be a point on the building wall. Show that the distance from \(P\) to \(M\) is
\(d(x)=\sqrt{0.015625x^4-x^2+64}\).
c) Find the \(x\)-coordinates where the wall is closest to \(M\), and find the minimum distance.
d) A second model over the same interval uses \(g(x)=\sqrt{64-x^2}\). By what percent does the cross-sectional area under \(f\) differ from the area under \(g\)? Use the area under \(g\) as the reference value.
Hints
- Use the zeros and vertex of the parabola to determine the building’s width and height.
- Apply the distance formula from \((0, 0)\) to \((x, f(x))\).
- To minimize a square root, you may minimize its nonnegative radicand instead.
- Recognize \(g(x)=\sqrt{64-x^2}\) as the upper half of a circle.
- Divide the area difference by the stated reference area when computing the percent difference.
Solution
1. For part a, \(f(-8)=f(8)=0\), so the floor extends from \(x=-8\) to \(x=8\) and is \(16\,\text{m}\) wide. The parabola opens downward and has vertex \((0, 8)\), so its maximum height is \(8\,\text{m}\).
2. For part b, the distance formula gives
\(d(x)=\sqrt{x^2+[f(x)]^2}\)
\(=\sqrt{x^2+(8-0.125x^2)^2}\)
\(=\sqrt{0.015625x^4-x^2+64}\).
3. For part c, minimizing \(d(x)\) is equivalent to minimizing its nonnegative radicand
\(q(x)=0.015625x^4-x^2+64\).
Differentiate:
\(q'(x)=0.0625x^3-2x=x(0.0625x^2-2)\).
The critical points are \(x=0\) and \(x=\pm\sqrt{32}=\pm 4\sqrt{2}\). The point \(x=0\) gives a local maximum of \(q\), while \(x=\pm 4\sqrt{2}\) give minima. The minimum distance is
\(d(4\sqrt{2})=\sqrt{0.015625(32)^2-32+64}=\sqrt{48}=4\sqrt{3}\approx 6.93\,\text{m}\).
4. For part d,
\(A_f=\int_{-8}^{8}(8-0.125x^2)\, dx=\frac{256}{3}\,\text{m}^2\).
The graph of \(g\) is the upper semicircle of radius \(8\), so
\(A_g=\frac{1}{2}\pi(8)^2=32\pi\,\text{m}^2\).
The percent difference relative to \(A_g\) is
\(\frac{A_g-A_f}{A_g}\cdot 100\%=\left(1-\frac{8}{3\pi}\right)100\%\approx 15.1\%\).
Thus the parabolic model has about \(15.1\%\) less cross-sectional area.
Answer
a) The floor width is \(16\,\text{m}\), and the maximum height is \(8\,\text{m}\).
b) \(d(x)=\sqrt{0.015625x^4-x^2+64}\).
c) The wall is closest at \(x=\pm 4\sqrt{2}\approx\pm 5.66\). The minimum distance is \(4\sqrt{3}\approx 6.93\,\text{m}\).
d) The area under \(f\) is about \(15.1\%\) less than the area under \(g\).
